Leather Resistance Flexing Tester H053AN

Leather Resistance Flexing Tester H053AN

Model :
H053AN
Brand :
UTSTESTER
Certificate :
CE, ISO 17025
Lead Time :
10-15 Days
Payment :
TT, LC
Original Region :
MADE IN CHINA
Port Of Dispatch :
CHINA PORT
Standards :
EN 13512 ; EN344-1 section 5.13.1.3 and annex C;EN ISO 20344 section 6.6.2.8;GB/T20991 section 6.6.2.8;AS/NZS 2210.2 section 6.6.2.8GE-24; JIS-K6545;SATRA TM 55;IULTCS/IUP 20-1;ISO5402-1: 2011; ISO 17694

Inquiry

Overview

To determine resistance to flex property for leather, fabric, etc. Assess the flexing resistance of leather by damage condition of samples after flexing for a certain of times.

Test Principle

Fix one end of sample on the upper fixture, the other end onto bottom fixture to make sample at 90. Then flex sample at a specified speed and angle. After flexing for a certain of times to assess damage degree of sample.

Features

1. Upper fixtures are driven by motor to do reciprocating motion with horizontal shaft. Downward moving angle is 22.5 0.5.

2.Flexing times can be set and real flexing times is display at real time.

3.Counter stop to count when reached preset test times and machine stop to work automatically.

4.12 or 24 working positions can be optional.

5.With manual location function.

Standards

EN 13512 ; EN344-1 section 5.13.1.3 and annex C;EN ISO 20344 section 6.6.2.8;GB/T20991 section 6.6.2.8;AS/NZS 2210.2 section 6.6.2.8GE-24; JIS-K6545;SATRA TM 55;IULTCS/IUP 20-1;ISO5402-1: 2011; ISO 17694

Key Parameters
