1 Function introduction

The instrument is designed by absorbing the advantages of similar instruments at home and abroad, using touch screen display, frequency converter + frequency conversion motor drive, internal and external bladder all adopts 306 stainless steel and other instruments, stable operation, low noise, easy maintenance.

The instrument is suitable for all kinds of textiles, non-woven fabrics, leather and other post-shrinkage and relaxation rate test.

2 Standards

GB/T8629、GB/T8630、 ISO6330/5077、FZ/T70009、BS4923、EN25077/26330 、JIS L1909、IWSTM31、IEC456 M&S

3 feature

1.All technical indicators of the instrument fully meet the requirements of ISO 6330-2012 standard.

2.the instrument adopts the fully independent suspension roller technology, high shockproof performance, super silent operation, without fixing the foot.

3.Adopt high performance stepless variable speed motor, high speed dehydration coefficient, digital setting.

4.Color touch screen Chinese display, easy to operate.

5.Adopts 32-bit Cortex-M3 microprocessor, fast data processing speed, sensitive instrument response, stable and reliable operation.

6.Adopt high precision electronic pressure sensor to ensure accurate and reliable water level.

7.The temperature control adopts the optimized PID algorithm, the heating speed is fast, the control fluctuation is small.

8.Built-in 10 sets of GB/T 8629 programs, 13 sets of ISO 6330 programs;3 sets of custom procedures, 1 set of manual single program.

9.Adopt stainless steel metal handle and high pressure glass window to ensure the door is more solid and durable.

4 The main technical parameters

For more information about Wascator Automatic Shrinkage Tester , please contact us.
