1. The Importance of Drop Testing

Drop testing simulates the impact conditions that products may encounter during transportation and storage to evaluate the protective performance of packaging. Good packaging must not only protect products from external environmental damage, but also provide cushioning when impacted to reduce the risk of product damage. Drop testing is crucial for evaluating the rationality and effectiveness of packaging design.

2. Drop Test Standards

2.1 Height Standards: The height for drop tests is typically determined based on the product's weight, dimensions, and fragility. Generally, drop heights are categorized into several levels, such as 30 cm, 50 cm, and 100 cm. The appropriate drop height should be selected based on actual conditions during testing.

2.2 Number of Drops Standards: The number of drops in a drop test is also an important indicator for evaluating packaging performance. Generally, the more drops, the better the packaging's protective performance. Common drop test frequencies include 1 time, 2 times, 3 times, etc., with the specific frequency determined based on product characteristics and test requirements.

2.3 Angle Standards: The angles used in drop tests typically include 90 degrees, 45 degrees, and 0 degrees. Drops at different angles can simulate various impact scenarios that products may encounter during transportation, thereby more effectively evaluating the protective performance of the packaging.

3. Drop Test Method

3.1 Preparation: Before conducting the drop test, ensure that the product is properly placed inside the packaging and sealed according to actual transportation conditions. Prepare the drop test equipment, such as a drop test machine or manual drop device.

3.2 Selecting Drop Height and Number of Drops: Based on product characteristics and test requirements, select an appropriate drop height and number of drops. Ensure that the product is not damaged during the test.

3.3 Conducting the Drop Test: Drop the product at the predetermined height and angle, observing the deformation of the packaging during the drop and whether the product is damaged. If necessary, use high-speed cameras or other equipment to record the drop process for subsequent analysis.

3.4 Analyzing Test Results: Evaluate the protective performance of the packaging based on observations and analysis during the drop test. If defects in the packaging or product damage are detected, promptly improve the packaging design or adjust the drop test parameters.

4. The Significance of Carton Drop Tests for Product Transportation

4.1 During transportation, products may be subjected to various operations (such as accidental drops during manual handling, falls during forklift transfers, stack collapses, or collisions during loading/unloading) that can cause them to fall. The angle of impact (face, edge, or corner), height, and impact force vary, resulting in significant differences in the extent of damage to the products. By simulating drop scenarios under different conditions, potential risk points that could lead to product damage during actual transportation (such as carton rupture when dropped on a specific face or internal product deformation due to pressure when dropped on a specific corner) can be identified in advance, thereby preventing issues from arising during actual circulation.

4.2 After drop testing, inspections of the carton and internal products can directly identify weaknesses in packaging design or materials.

4.3 Based on defects identified through testing, targeted packaging improvements can be made to fundamentally enhance protective performance.

The core value of carton drop testing lies in “proactively identifying risks, quantifying packaging performance, and guiding precise optimization.” By simulating real-world impacts, identifying defects, and improving designs, packaging can effectively protect products, reduce damage rates during transportation from the source, lower costs associated with returns and claims for businesses, and simultaneously enhance customer satisfaction.
